The LZG(A) 200 Curved Bowl with Separating Unit is a specialized industrial device designed for automatic discharge of materials after mixing, stirring, or feeding. It is widely applied in the food, cosmetics, pharmaceutical, and chemical industries. With its curved bowl design and advanced vibration discharge mechanism, the machine improves discharge efficiency, minimizes residue, saves time, and reduces labor costs.
Key Features
-
Automatic vibration discharge system ensures fast, uniform, and clean material release
-
Curved bowl design minimizes material residue and guarantees hygiene
-
Compact size, easy to install into production lines
-
Constructed from high-quality stainless steel (SS304 or SS316L) for durability and safety
-
Stable motor performance, with customizable power options to match production scale
Technical Specifications – Model LZG(A) 200
| Model | Total Volume (L) | Max overall dimention A (mm) | Motor installation tube Ø B (mm) | Process bowl width C (mm) | Unload width D (mm) | Machine height H1 (mm) | Unload height H1 (mm) | Motor (Kw) | Weight (Kg) |
|---|---|---|---|---|---|---|---|---|---|
| LZG(A)100 | 30 | 670 | 136 | 184 | 200 | 800 | 760 | 0.5 | 85 |
| LZG(A)200 | 63 | 830 | 114 | 280 | 245 | 910 | 780 | 0.75/1.1 | 110 |
| LZG(A)300 | 100 | 1020 | 470 | 216 | 330 | 860 | 760 | 1.5/2.2 | 260 |
| LZG(A)600 | 220 | 1200 | 625 | 220 | 385 | 915 | 960 | 3.0 | 420 |
| LZG(A)900 | 250 | 1310 | 620 | 270 | 390 | 900 | 1220 | 3.75/5.0 | 600 |
